KEY FEATURES:
●Heavy duty jockey wheel
●6 leaf tandem roller rocker suspension spring
●Heavy duty 50mm solid axles
●14'Aluminum Alloy Rims
●Five LINGLONG Tyre 185-R14LT
●LED tail lights & side lights
●High Stop brake light
●Double axle electric brakes,front axle also with hand brake
●2 internal & 4 external tie hooks
CONSTRUCTION
●Fully hot dipped galvanised chassis
●Galvanised steel frame & panel
●Aluminium front stone guard
●Stainless steel door locks, latches & tie hooks
●Fully lockable
●Gas strut assisted rear opening ramp with rubber matting
●Gas strut assisted rear upper door
INTERIOR
●High Density TUFF Board floor (no concerns of rot or crack) with Rubber matting
●Internal TUFF Board kickboards on both sides
●Padded Dividers
●Interior LED lights
●Sliding windows on each side with mesh screen
●Reinforced fiberglass roof with carpet lining
●Two opening roof vents
●Front Rug Rack
DIMENSIONS:
INTERNAL DIMENSIONS
●Height: 2155mm
●Width: 1730mm
●Length: 3050mm
OVERALL DIMENSIONS
●leight: 2590mm
●Width: 2290mm
●Length: 3925mm
●Tare weight: 1200KGS
●Gross Trailer Mass:2800KGS
●Aggregate Trailer Mass:3000KGS
* All Horse Floats are complied with Australia ADR standards.
* MOQ:1 unit with 1x40HC container
* Customized Painting Color Available
* Welcome OEM & ODM orders.
